Vernacare Vortex+ - Page 21

Page | 21
KIT
REF
PART DESCRIPTION
KIT NUMBER
ITEM NUMBER
1
Lid Arm Assembly Kit
9207034
1.1
Lid Arm Bottom
9200843
1.2
Lid Arm Top
9200842
1.3
Lid
9200103
1.4
Extension Bracket
9200932
1.5
Arm Seal
9200853
1.6
Lid to Arm Seal
9200109
1.7
Hinge Bush (x2)
9200146
1.8
Press Lok Insert
9200115
1.9
Lid Spray Washer
9200117
1.10
Self-Tapping Screw (x2)
9200120
1.11
Lid Spacer Short (x2)
9200122
1.12
Lid Spacer Long (x2)
9200856
1.13
M5 Nyloc Nut (x4)
9750012
1.14
Arm Inlet Pipe
9200162
1.15
D8 Spring Washer
9750033
1.16
D5 Plain Washer (x4)
9750011
1.17
Lid Arm Label
9200860
1.18
Arm Hinge Shaft (x2)
9200113
1.19
Hinge Block (x2)
9200114
1.20
M10 Aero Nut (x2)
9200865
1.21
M10 Plain Washer (x4)
9200866
1.22
Torx Head Self-Tapping Screws (12)
9200924
1.23
Linear Actuator
9200854
1.24
Neodymium Magnet
9200837
