9 • Model E1 Metallic Bolted
Composite Repair Parts List
Air Valve Assembly
Item # Qty. Description Part Number
- 1 Air Valve Assembly (includes items 1-10) 031.V006.156
1 1 Valve Body P98-102UB
2 1 Valve Spool Assembly (Includes items 3&4) P98-105UB ASY
3 1 Large Valve Spool U-Cup P98-105B
4 1 Small Valve Spool U-Cup P98-105A
5 2 Metal End Cap P98-300
6 2 End Cap Gasket (for metal) P98-110
7 1 CT Air Diverter P98-105CT
8 1 Air Diverter Plate P98-106
9 1 Air Valve Gasket P98-111UB
10 12 Mounting Screws S1001
Center Section Assembly
Item # Qty. Description Part Number
11 1 Center Section 114.V001.157
12 1 Pilot Spool ASY (includes item 13) 775.V005.000
13 7 Pilot Spool O-Rings 560.023.360
14 1 Pilot Valve Sleeve ASY (includes item 15) 755.V004.000
15 6 Pilot Valve Sleeve O-Rings 560.101.360
16 2 Shaft/Pilot Retainer 670.V002.554
10 4 Retainer Screw S1001
17 1 Mufer VTM-4A
Diaphragm Assembly / Elastomers
Item # Qty. Description
Part Number
TPE/RUBBER PTFE 2-Piece PTFE Fusion
18 2 Main Shaft O-Ring P50-403
19 1 Main Shaft 685.V001.120 P50-108
20 2 Diaphragm V183BN-1 V183TF-1 V183F
21 2 Back-Up Diaphragm N/A V183TB N/A
22 2 Inner Diaphragm Plate V181C V181C N/A
23 2 Outer Diaphragm Plate (See Note 1 Below) V81B SV181TO N/A
24 4 Valve Seat O-Ring V90BN SV190TF
25 4 Valve Ball V191BN V191TF
Wet End Assembly
Item # Qty. Description
Part Number
Aluminum Stainless Steel
26 4 Valve Seat V90A SV190
27 2 Water Chamber V85 SV185
28 16 Water Chamber Bolt V189A SV189D
29 16 Water Chamber Washer V189C SV189C
30 16 Water Chamber Nut V185B SV185B
31 1 Discharge Manifold V86 SV186
32 1 Suction Manifold V87 SV187
33 8 Manifold Bolt V187A SV187A
29 8 Manifold Washer V189C SV189C
30 8 Manifold Nut V185B SV185B
MODEL SPECIFIC
3: EXP VIEW
