Model E1 Metallic Bolted • 12
UNIT PARTS BEING REMOVED
Item # Part Number Description Qty.
12 775.V005.000 PILOT SPOOL 1
14 755.V004.000 PILOT SLEEVE 1
16 670.V002.554 RETAINER 2
24 V181C INNER PLATE (PTFE FITTED PUMPS ONLY) 2
SUPPLEMENT SHEET FOR
SERVICE MANUAL - e1mdlCsmATEXUL
PUMP MODEL - 1" Elima-Matic Bolted Metal - UL Listed w - Metallic Center Section
PARTS BEING REPLACED WITH
Item # Part Number Description Qty.
E101B RETAINER 2
P24-106P PILOT SPACER 5
P24-107 PILOT VALVE O-RING 6
P24-108 JAM NUT 2
P50-112 PILOT SHAFT 1
V181TI INNER PLATE (PTFE FITTED PUMPS ONLY) 2
