PAGE 7
3. PARTS INTRODUCTION
1
6
7
8
9
2
3
4
5
Parts Description
1. Power Switch
2. Charger Socket Cover
3. Basket Bracket
4. Tiller Adjust Lever
5. Seat Rotate Lever
6. Armrest
7. Width Adjustable
Armrests Knob
8. Circuit Breaker
9. Under-seat Storage
10. Freewheel Lever
11. Anti-tip Wheel
12. Connecting Device
13. Wheel Lock knob
13
10
12
11
