Vertex PWC-1500 User Manual

PWC-1000 Parts List
Item No. Description Part Number Price Item No. Description Part Number Price
1 Top Cover cl1- 9200 30 Silicon Vent "T" cl1- 9225
2-1 Dust Cover cl1- 9201 31 Silicon Tube Straight 250 x 2 cl1- 9226
3 Upper Front Panel cl1- 9202 32 Silicon Tube Elbow 160 x 4 cl1- 9227
4 Lower Front Door cl1- 9203 33 Silicon Tube Elbow 50 x 60 x 4 cl1- 9028
5 Base cl1- 9204 34 Hot Tank cl1- 9029
6 Drip Tray Base cl1- 9205 35
7 Drip Tray cl1- 9206 36
8 Hot Tap w/Safety cl1- 9207 37 Silicon Tube Elbow, 175 x 4 cl1- 9230
9 Cold Tap cl1- 9208 38 Screw, 3 x 8 cl1- 9231
10 Indicating Panel (sticker) cl1- 9209 39 Vertex Emblem cl1- 9232
11-1 Main Water Tank Cover cl1- 9210 40 Mechanical Float Valve cl1- 9233
12 Left Side Panel cl1- 9211 41 Tubing, 1/4" cl1- 9234
13 Right Side Panel cl1- 9212 42 Handle cl1- 9235
14 Bracket cl1- 9213 43
15 Insulating Sleeve cl1- 9214 44 Rear Cover cl1- 9236
16 Spring Clip cl1- 9215 45 Cold Temperature Switch cl1- 9237
17 Screw 4 x 8 black cl1- 9216 46 Power Switch cl1- 9238
18 47
19 48 Condenser cl1- 9239
20 49 Drain Fitting Nut cl1- 9240
21 Mounting Plate cl1- 9217 50 Dryer cl1- 9241
22 Compressor cl1- 9218
23 Mounting Plate cl1- 9219 52 Cold Tank Outlet Connector cl1- 9242
24 Faucet Bracket cl1- 9220 53 Tap Nut cl1- 9243
25 Bottom Insulator cl1- 9221 54 Silicon Tube SL-04 cl1- 9244
26 Upper Insulator cl1- 9222 55 Screw, Hot Tank cl1- 9245
27 Cold Water Tank cl1- 9223 56
28 57 Tank Drain Connector cl1- 9246
29 Silicon Gasket cl1- 9224 58 Strain Relief cl1- 9247
VERTEX WATER PRODUCTS
2005
1 of 2
