Vertex PWC-1500 - Cooler Set-Up; Feedwater;Drain Connections

PWC – 500/1000/1010/1500
PureWaterCooler
Copyright 2006 Vertex Water Products
Feedwater/Drain Connections
-Feed Connection
2.1 Open hinged door to access filter
compartment
2.5 Remove feed water plug (orange) from back
of cooler.
2.6 Connect supplied orange feed water tubing to
feed connector on back of cooler.
2. Cooler Set-Up (for new cooler installation)
