Vertex T22.1 - Assembly Steps

2015/5/6V1.2+V1.1
11
3.2. Hardware Pack
ITEM
Description
Qty
a
Cks hex screw M10xP1.5x25
8
b
Truss hex screw∮13
4
c
Truss Philips Screw M5xP0.8x12
4
d
Screw Φ4x16
4
e
Philips screw M5xP0.8x15
4
f
Truss hex screw M8xP1.25x20
2
g
Spring washer M8
2
h
L hex wrench+ Philips Screwdriver 5mm
1
i
L hex wrench 10mm
1
j
L hex wrench 8mm
1
k
SILICONE
1
l
Spring washer M4
2
m
Truss Philips Screw M4xP0.7x10
2
n
Power Cord Switch Cover
1
o
CABLE Adapter
1
