Vertex VX-410 series Service Manual

28
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE
LAY ADR
Q 1011 FET 2SK3541 T2L G3835417 1- B d3
Q 1012 TRANSISTOR CPH6102-TL G3070223 1- B e3
Q 1013 TRANSISTOR UMX1N TN G3070324 1- B e2
Q 1014 FET RD01MUS1(TAPE) G3070321 1- B c1
Q 1015 IC M62364FP 600D G1093033 1- B d1
Q 1016 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B d1
Q 1017 TRANSISTOR CPH6102-TL G3070223 1- B e3
Q 1018 TRANSISTOR UMX1N TN G3070324 1- B e3
Q 1019 TRANSISTOR 2SC5006-T1 G3350068 1- B a2
Q 1020 TRANSISTOR 2SC5227-4-TB G3352278D 1- B c1
Q 1021 IC AK2342B G1093143 1- B e1
Q 1022 TRANSISTOR DTB123EK T146 G3070022 1- B e3
Q 1025 IC NJM2871AF35(TAPE) G1093899 1- B e3
Q 1026 TRANSISTOR 2SC5005-T1 G3350058 1- B c1
Q 1027 TRANSISTOR 2SC4154-T11-1E G3341548E 1- B b2
Q 1028 TRANSISTOR DTC144EE TL G3070075 1- B c2
Q 1029 FET 3SK320(TE85L) G4803208 1- B b2
Q 1030 FET 2SK210GR TE85R G3802107G 1- B c2
Q 1031 TRANSISTOR DTC144EE TL G3070075 1- B c1
Q 1032 TRANSISTOR DTC144EE TL G3070075 1- B c2
Q 1033 TRANSISTOR 2SC5226-4/5-TL G3352268Z 1- B c2
Q 1034 TRANSISTOR 2SC4154-T11-1E G3341548E W/LCD 1- A C3
Q 1035 TRANSISTOR DTC114TE TL G3070225 W/LCD 1- A B3
Q 1036 IC BR93L56RFVM-WTR G1093928 1- A D2
Q 1037 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A D2
Q 1038 FET 2SK3541 T2L G3835417 1- B e2
Q 1039 TRANSISTOR DTA144EE TL G3070074 1- A D3
Q 1040 IC BD4835FVE-TR G1093967 1- A D3
Q 1041 TRANSISTOR 2SC4215Y TE85R G3342157Y 1- B b2
Q 1043 TRANSISTOR UMC5N TR G3070137 1- B d1
Q 1044 TRANSISTOR 2SC4154-T11-1E G3341548E 1- A E1
Q 1045 TRANSISTOR 2SC4154-T11-1E G3341548E W/LCD 1- A C3
Q 1046 TRANSISTOR DTC114TE TL G3070225 W/LCD 1- A C3
Q 1047 IC LC87F74C8A-TQFP-E  1- A C2
Q 1048 IC TA31136FN(EL) G1091605 1- B c2
Q 1051 IC MB15A01PFV1-G-BND-EF G1092545 1- B d1
Q 1052 TRANSISTOR DTC144EE TL G3070075 1- B d3
Q 1054 IC NJM12904R(TE1) G1093337 1- A D2
Q 1055 FET 2SK3541 T2L G3835417 1- B e1
Q 1056 TRANSISTOR DTC144EE TL G3070075 1- B d3
Q 1058 TRANSISTOR CPH6102-TL G3070223 1- B e2
Q 1059 TRANSISTOR UMX1N TN G3070324 1- B e2
Q 1060 IC NJU7007F2-TE1 G1093617 1- B d1
Q 1061 TRANSISTOR DTC144EE TL G3070075 1- B d2
Q 1062 IC TC7W74FU TE12R G1091788 1- B e1
Q 1063 TRANSISTOR UMX1N TN G3070324 1- A E1
R 1002 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A E1
R 1003 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A D1
R 1004 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C1
R 1005 CHIP RES. 2.2 1/16W 5% RMC1/16 2R2JATP J24185229 1- A E2
R 1006 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A E2
R 1007 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1008 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1009 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1010 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 1011 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B a1
R 1013 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1014 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B a1
R 1015 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A E1
R 1016 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A E1
R 1017 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1018 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A E1
R 1020 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A E1
R 1021 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A E1
R 1022 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1023 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C1
R 1024 CHIP RES. 56k 1/16W 5% RMC1/16S 563JTH J24189046 1 A C1
 Please contact VERTEX STANDARD.
MAIN Unit
