DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE
LAY ADR
R 1091 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e3
R 1092 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e3
R 1093 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a2
R 1094 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1095 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d1
R 1096 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B b1
R 1097 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a2
R 1098 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 1099 CHIP RES. 15 1/16W 5% RMC1/16S 150JTH J24189003 1- B c1
R 1100 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- B c1
R 1101 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B c1
R 1102 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1104 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B d1
R 1106 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1107 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B e1
R 1108 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1109 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d1
R 1110 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B e1
R 1111 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 1112 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d1
R 1113 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B e1
R 1114 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B e1
R 1115 CHIP RES. 120k 1/16W 5% RMC1/16S 124JTH J24189050 1- B e1
R 1116 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e1
R 1117 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B e1
R 1118 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 1119 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B e1
R 1120 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B e2
R 1121 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 1122 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e2
R 1123 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 1124 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A E2
R 1125 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D2
R 1126 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A E2
R 1127 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A E2
R 1128 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1129 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a2
R 1130 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1131 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1134 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c2
R 1135 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B c2
R 1137 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B c2
R 1138 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
R 1139 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B e1
R 1140 CHIP RES. 1.5M 1/16W 5% RMC1/16S 155JTH J24189063 1- B e1
R 1141 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d2
R 1142 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e1
R 1143 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e1
R 1144 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B e1
R 1145 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e2
R 1146 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a3
R 1147 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B b2
R 1148 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 1149 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
R 1150 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c2
R 1151 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B c2
R 1152 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c2
R 1153 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 1154 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B c2
R 1155 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- B c2
R 1156 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 1157 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 1158 CHIP RES. 82 1/16W 5% RMC1/16S 820JTH J24189012 1- B b2
R 1159 CHIP RES. 560 1/16W 5% RMC1/16S 561JTH J24189022 1- B b2
R 1160 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 1161 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B c2
R 1162 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
MAIN Unit
