REV : 0
REV DATE : 11/18
DPN004865
Page :1 /1
CW305, 375, 415 DOWNFLOW UNIT W/ HORIZONTAL DISCHARGE
Form No.: DPN001040_REV4
AIRFLOW SCHEMATIC
LIEBERT CW
Return Air
from Data Center
Supply Air
to Data Center
Front (Data Hall Side)
114"
2896mm
70"
1779mm
7 1/2"
189mm
10 1/2"
267mm
3"
76mm
1 3/4"
44mm
Duct
Flange
Notes:
1. Electrical Compartment shown on left side of unit.
Unit may be ordered with Electrical Compartment on right or left side, or with Electrical Compartment
facing into the Gallery space.
1
61"
1550mm
Fan
Section
53 1/8"
1348mm
Outside of
Duct Flange
115 3/8"
2929mm
Outside of
Duct Flange
4 3/8"
111mm
2 3/8"
60mm
