Vertiv Liebert CW - Page 60

REV : 0
REV DATE : 11/18
DPN004866
Page :1 /1
CW305, 375, 415
Form No.: DPN001040_REV4
FLOORSTAND DIMENSIONAL DATA
LIEBERT CW
12 (305)
24 (610)
30 (762)
36 (914)
42 (1069)
48 (1219)
Height in. ( mm )
A
Notes:
1. Leveling feet are provided with u 1-1/2” (38mm) adjustment from nominal height “A”.
2. Dimensions are to center of feet.
3. Floorstand shown in configuration for Electrical Box on the left side of the unit. When unit is
ordered with the Electrical Box on the right side of the unit, cantilevered portion of floorstand will appear on the right side.
1
2
2
2
2
2
2
2
2
2
Front View Right Side View
Top View
A
60"
1524mm
Overall
Depth
143 3/4"
3651mm
Overall
Length
116 1/4"
2953mm
33 7/8"
860mm
43 1/2"
1105mm
Typ. (2) Plcs.
36 3/8"
924mm
56 1/4"
1430mm
Typ.
28 1/8"
715mm
Typ. (2) Plcs.
33 7/8"
860mm
36 3/8"
924mm
2 1/2"
64mm
Typ. (2) Plcs.
24"
610mm
46"
1168mm
