REV : 0
REV DATE : 2/19
DPN004870
Page :1 /3
Form No.: DPN001040_REV4
INSTALLATION & SERVICE CLEARANCE DATA CW305-415
LIEBERT CW
Wall
Piping & Cables
can be routed
in this zone.
66"
(1676mm)
Full Unit and Electrical Panel Access
Full Unit and Electrical Panel Access
Data Hall
Notes:
1. Electrical Compartment is shown on the right side of the unit.
Unit may be ordered with Electrical Compartment on either side,
or with Electrical Compartment facing into Gallery Space.
PERIMETER INSTALLATION AND SERVICE CLEARANCE HORIZONTAL DISCHARGE
