INSTALLATION & SERVICE CLEARANCE DATA CW305-415
LIEBERT CW
Notes:
1. Electrical Compartment is shown on the right side of the unit.
Unit may be ordered with Electrical Compartment on either side,
or with Electrical Compartment facing into Data Hall.
Wall
Piping and Cables
can be routed
in this zone.
66"
(1676mm)
Full Unit and Electrical Panel Access
Unit Disassembly access and
Electrical Panel access
Gallery Side
PERIMETER INSTALLATION AND SERVICE CLEARANCE BOTTOM DISCHARGE
