Notes:
1. Cable lances are typically
located on equipment rails.
32” Deep Enclosure, No Side Chamber (30” Wide)
(Enclosure with Battery Base Shown, Plinth and Riser Similar)
25” Deep Enclosure, No Side Chamber (30” Wide)
(Enclosure with Battery Base Shown, Plinth and Riser Similar)
OSP Cables
Right Side View Front View
Equipment
Compartment
Equipment
Compartment
Cable Entry
Compartment
Front View
Right Side View
OSP Cables OSP Cables
Cable Entry
Compartment
