Vertiv NetXtend Flex 20 - Optional 60 A Generator Connection Kit P;Ns 546478 and 547098 - Typical Wiring

NOTES: 1. CONNECT OPTION X OR Y PER LOCAL CODE. 2. SECURE BREAKER RETAINING BRACKET
TO PREVENT REMOVAL OF MAIN AC BREAKER
AND GEN. BREAKERS.
3. HANDLE TIE TO BE MOUNTED ON THE MAIN
AND GEN. BREAKERS TO PREVENT BOTH
BEING ON AT THE SAME TIME.
TO METERED
OVER C URRENT
PROTECTED SINGLE
PHASE 120/240V OR
120/208V SER VICE
SHOWN FOR
REFERENCE ONLY.
WIRES INSTALLED
IN FIELD.
WHT
RED BLK
GRN
AC LOAD CENTER
NOTE 2
WHT
BLK RED
GRN
CB1
CB2
CB3
60A
60A
15A
Y
X
WHT
BLK
GRN
GRN
BLK
14 AWG
WHT
SURGE
ARRESTOR
GROUND BAR
TO
MAIN
GROUND
BAR
GFI
J2 (GFI)
LINE
LOAD
GND
TEST
RESET
GND
OPTIONAL BATTERY
HEATER
GRN
GND
BLK
T’STAT
HEATER
ELEMENT
S1
10A
SC-10
NEUTRAL BAR
WHT
GRN / YEL
WHT
RED
BLK
GRN
60A
AC GENERATOR
PLUG
(FRONT VIEW)
60A
AC GENERATOR
PLUG
(REAR VIEW)
WHT
RED
BLK
GRN
14 AWG
NOTE 3
CB4
15A
INTERLOCK
6 AWG
6 AWG
WHT
BLK
BLK
J1 (GFI)
