NOTES:
1. CONNECT OPTION X OR YPER LOCAL CODE.
2. SECURE BREAKER RETAINING BRACKET
TO PREVENT REMOVAL OF MAINAC BREAKER
AND GEN. BREAKERS.
3. HANDLE TIE TO BE MOUNTED ON THE MAIN
AND GEN. BREAKERS TOPREVENT BOTH
BEING ON AT THE SAME TIME.
TO METERED
OVER CURRENT
PROTECTED SINGLE
PHASE 120/240V O R
120/208V SERVI CE
SHOWN FOR
REFERENCE ONLY.
WIRES INSTALLED
IN FIELD.
WHT
RED
BLK
GRN
AC LOAD CENTER
SEE NOTES
2 & 3
CB1
CB2
CB3
100A
30A
15A
WHT
BLK
GRN
GRN
BLK
10 AWG
THHN
WHT
SURGE
PROTECTOR
GROUND BAR
TO
MAIN
GROUND
BAR
GFI
LINE
LOAD
GND
TEST
RESET
GND
OPTIONAL BATTERY
HEATER
GRN
GND
BLK
T’STAT
HEATER
ELEMENT
S1
10A
SC-10
NEUTRAL BAR
WHT
WHT
RED
BLK
GRN
30A
AC GENERATOR
PLUG
(FRONT VIEW)
30A
AC GENERATOR
PLUG
(REAR VIEW)
WHT
RED
BLK
GRN
14 AWG
CB4 15A
WHT
BLK
BLK
WHT
WHT
BLK
GRN
NEUTRAL BAR
14 AWG
WHT
RED
BLK
GRN
W
L1
L2
G
