each
M307
requires a
ground
wire to
the U-channel
ground
each U-channel has ground bar
and ground wire
Main enclosure ground bar
: Ground straps from each individual blocks will be connected
to protection bracket ground bar. Another ground strap will connect
the main ground bar with each protection bracket ground bar (of each
vertical bracket).
This grounding scheme is the same for side chamber
protection layout as well.
