32” Deep Enclosure
No Side Chamber (30” Wide)
(Enclosure with Battery
Base Shown, Plinth
and Riser Similiar)
32” Deep Enclosure
One Side Chamber (42” Wide) Shown
Two Side Chambers (54” Wide) Similiar
(Enclosure with Battery Base
Shown, Plinth and Riser Similiar)
R
i
g
h
t
S
i
d
e
Equipment
Compartment
Cable Entry
Compartment
AC and Ground
Cable Entry Conduits
R
i
g
h
t
S
i
d
e
Side Chamber
Cable Entry
Compartment
AC and Ground
Cable Entry
Conduits
25” Deep Enclosure
No Side Chamber (30” Wide)
(Enclosure with Battery Base
Shown, Plinth and Riser Similiar)
R
i
g
h
t
S
i
d
e
R
i
g
h
t
S
i
d
e
25” Deep Enclosure
One Side Chamber (42” Wide) Shown
Two Side Chambers (54” Wide) Similiar
(Enclosure with Battery Base
Shown, Plinth and Riser Similiar)
Equipment
Compartment
Cable Entry
Compartment
AC and Ground
Cable Entry Conduits
Side Chamber
Cable Entry
Compartment
AC and Ground
Cable Entry
Conduits
