9. Fuse No. 3; 15A
10.Engine stop switch
11.Fuse No. 2; 7.5A
12.Injection load remote controls
13.Fuse No. 5; 15A
14.Starter button
15.Start-up remote control switch
16.Electric fan remote control
17.Starter motor
18.Electric fan motor
19.Fuel pump
20.HV coil
21.Injector
22.Lambda sensor
23.Headlight remote control
24."WARNING" light
25."IMMOBILIZER" led
26.Diagnostics socket output
27.Coolant electric pump
Troubleshooting procedure
Engine does not start
ENGINE DOES NOT START IF ONLY PULLED
Possible Cause
Operation
Immobiliser enabling signal System not encoded
System not efficient, repair according to the indications of the
self-diagnosis
Presence of faults detected by the self diagnosis Pump relay
HV coil
Injector
Revolution timing sensor
Fuel system Fuel in the tank
Fuel pump activation
Fuel pressure (low)
Injector capacity (low)
Power to the spark plug Shielded spark plug cap HV coil (secondary insulation)
Parameter reliability Coolant temperature
Distribution timing - injection ignition
Intake air temperature
End of compression pressure End of compression pressure
Vespa GTS Super 125 i.e. (2009) Injection
INJEC - 103
