CAUTION
HAVE THE BRAKE PADS CHECKED BY THE DEALER ACCORDING TO THE
CHECKS SPECIFIED IN THE SCHEDULED MAINTENANCE TABLE. HOWEVER,
IN THE EVENT OF NOISES COMING FROM THE FRONT AND/OR REAR BRAK-
ING SYSTEM DURING OPERATION, IT IS ADVISABLE TO HAVE THE BRAKING
SYSTEM CHECKED BY AN AUTHORISED SERVICE CENTRE OR DEALER. AF-
TER REPLACING THE BRAKE PADS, DO NOT USE THE SCOOTER UNTIL YOU
HAVE OPERATED THE BRAKE LEVER SEVERAL TIMES IN ORDER TO ALLOW
THE PLUNGERS TO SETTLE AND THE LEVER STROKE TO BE SET TO THE
CORRECT POSITION.
CAUTION
THE PRESENCE OF SAND, MUD, SNOW MIXED WITH SALT, ETC. ON THE
ROAD, CAN DRASTICALLY REDUCE THE LIFE OF THE BRAKE PADS. IN OR-
DER TO AVOID THIS, WE RECOMMEND WASHING THE VEHICLE FREQUENTLY
WHEN RIDING IN THESE ROAD CONDITIONS.
03_36
Rear drum brake (03_36)
Operate adjusting nut «B» and loosen lock nut «A» shown in the figure. Note that
when the throttle is in idle the wheel should rotate free. After the adjustment, screw
lock nut «A».
CAUTION
BRAKING SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE.
59
