VESTEL RT 455S - Unit Parts List

VESTEL
WHITE GOODS
VESTEL
WHITE GOODS CONSUMER SERVICE
TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
18
Printed Date : 21 / 12 / 2001 Document No : 50024370
DECEMBER
2001
UNIT PARTS LIST
RD 36T - RD 40T - RD 46T
NO CODE PARTS NAME RD 36T RD 40T RD 46T
1 35004210 MAIN CONDANSER/345(D50) 1 1
1 35000751 MAIN CONDANSER/455 1
2
40002180
SPACER 2 2
2 40002263 UNIT COVER 1
3
35001817
SCREW 4.2*9.5 WITH WASHER
4 4
3 35000728 SCREW KA 50*14 WN 1412 EJOT 4
4
35001697
DRYER(XH9,10GR) 1 1 1
5 40002264 EVAPORATING TRAY 1 1 1
6 35000743 SCREW 4.2*9.5 DIN 7981 YSB 2 2 5
7 30007916 COMPRESSOR (FG75HAK,NL7FT) 1 1
7 30007910 COMPRESSOR (FG85HAK,NL9FT) 1
8 40007341 COMP.RUBBER 4 4 4
9 20020023 COMP FIXING BRACKET 2 2 2
10
20020103
COMP.BASEMENT GROUP/345
1 1
10 20020050 COMP.BASEMENT GROUP/455 1
11
20020108
COMP BASEMENT/345
1 1
11 20020020 COMP BASEMENT/455 1
12 30007904
GROUNDING WIRE
1 1 1
13 35000721 NUT M4*3.2 DIN 934 ZNK 2 2 2
14
35000722
WASHER 4.3*8*0.9 DIN 6798 ZNK 2 2 2
15 35000723 SCREW M4*16 DIN 933 ZNK 1 1 1
16
40002217
WHEEL 2 2 2
17 35000738 REAR WHEEL PIN 2 2 2
18 35000728 SCREW KA 50*14 WN 1412 EJOT 2 2 2
19 30007918 POWER CORD GR.FG85HAK/455-345 1 1 1
20 30007911 POWER CORD (2.1m) 1 1 1
21 30007909 OVER LOAD RELAY GR.FG85HAK/455-345 1 1 1
22 20020051 FAN MOTOR GR./455 1
23
30007905
WIRING HARNESS/FAN MOTOR/455 1
24 35002921 SCREW M4*10 DIN 7985 YSB 2
25
40002214
FAN BRACKET RUBBER 1
26 35000725 FAN MOTOR BRACKET 1
27
30007901
FAN MOTOR ASSY./455 1
28 40004182 COVER FAN MOTOR 1
29
40002210
ANTI - VIBRATION COND. 2 2 2
30
40004702
CONDENSER TRIM/345
1
