VESUVIO VESIN10 User Manual

For users
- 6 -
3. Technical specification
Model
VESIN10
VESIN13
VESIN17
VESIN28
VESIN36T
Advised pool volume (m
3
)
20-40
30-60
40-75
65-120
90-169
Working air temp (℃)
-7~43
Performance Condition: Air 26°C, Water 26°C, Humidity 80%
Heating capacity (kW)
9.8~2.4
13.3~3.4
17.3~4.4
27.9~7.1
36.2~9.2
Heating capacity (kW) in
silence mode
7.8~2.4
10.4~3.4
13.8~4.4
21.8~7.1
28.9~9.2
C.O.P
6.4~15.0
6.4~15.0
6.3~15.2
6.3~15.3
6.4~15.5
C.O.P in silence mode
7.4~15.0
7.4~15.0
7.3~15.2
7.3~15.3
7.4~15.5
Performance Condition: Air 15°C, Water 26°C, Humidity 70%
Heating capacity (kW)
6.5~1.7
9.4~2.3
11.4~2.8
18.0~4.6
24.0~6.2
Heating capacity (kW) in
silence mode
5.1~1.7
7.4~2.3
8.8~2.8
14.6~4.6
19.2~6.2
C.O.P
4.4~7.6
4.4~7.6
4.3~7.8
4.4~7.9
4.5~8.0
C.O.P in silence mode
5.1~7.6
5.1~7.6
5.2~7.8
5.1~7.9
5.2~8.0
Performance Condition: Air 35°C, Water 28°C, Humidity 80%
Cooling capacity (kW)
4.8~1.2
6.2~1.6
8.5~2.1
13.5~3.4
18.0~4.5
Rated input power (kW)
1.4~0.2
2.1~0.25
2.6~0.33
4.0~0.58
5.3~0.79
Rated input current (A)
6.4~0.86
9.1~1.1
10.9~1.4
17.4~2.5
8.0~1.1
Max input current (A)
9.0
11.0
13.5
21.0
9.5
Power supply
230V/1 Ph/50Hz
400V/3 Ph/50Hz
Advised water flux (m³/h)
3~4
5~7
6.5~8.5
10~12
12~18
Sound pressure 1m dB(A)
39.3~48.0
42.8~52.1
44.2~52.9
48.6~55.5
49.6~55.8
Sound pressure 10m dB(A)
19.3~28.0
22.8~32.1
24.2~32.9
28.6~35.5
29.6~35.8
Water pipe in-out Spec
(mm)
50
Net Dimension LxWxH
(mm)
961x312x658
961×312×658
961×392×658
1092×391×958
1161x496x958
Net Weight (kg)
49
52
63
93
117
1. The values indicated are valid under ideal conditions: Pool covered with an isothermal cover, filtration
system running at least 15 hours a day.
2. Related parameters are subject to adjustment periodically for technical improvement without further
notice. For details please refer to nameplate.
