VEVOR BT-FL16A - Page 9

- 8 -
Step 2:
1、If you are mounting onto anything other than a wood support or
stud, insert the included four wall anchors into the drilled mounting holes. You may
need to use a hammer to secure them through the holes. See the (Fig.5.)
2、Paste the cushion onto the flange bracket to ensure that the hole
of the cushion is aligned with the hole of the flange bracket. See the (Fig.6.)
3、Align the flange bracket’s holes with the wall anchors. Screw in
four wood screws with a screwdriver or drill to secure the flange bracket.Make sure
its airflow arrow is pointing in your desired direction.See the (Fig.7.)
4、Slide the motor box back into the flange bracket, making sure its
airflow arrow is pointing in the same direction as the flange bracket’s arrow.See the
(Fig.8.)
Fig.5.
Fig.6.
Fig.7.
Fig.8.
