in order to ensure the normal assembly.
3.2 Wind Turbine Generator Install Steps
1) The tower will be tilted (inclined angle to facilitate the installation of
wind turbines is appropriate); the two cables from the bottom of the tower
through the top hole out; and the wind turbine two lead connection,
wrapped with insulating tape Well, put the cable into the tower (as Figure 2
shows).
2) Install the wind turbine brackets into the tower bushings and align
them with four holes,with four M8*20 hex screws plus a Ø8 flat pad(see
Figure 3 / Figure 4) (Note: fan leads With 4mm²cable)
