Step 1: Use a 10 mm open wrench or
a 10 mm socket wrench to fix the
compressor to the car using M6 bolts,
four nuts, four flat washers, and four
rubber cushion pads. Install the bolts
through the gasket, compressor
support, rubber washers, car frame,
and nuts.
Step 2: Use a 10 mm open wrench
or a 10 mm socket wrench to fix the
horn support to the horn and the car
using four M6 bolts, four M6 nuts,
and one tripod. Install the bolts
through the tripod - one end through
the horn lock nut, and the other end
through the car lock nut.
2.1 Model HS-660 Horn assembly
Step 1：Use a 10mm open wrench
or a 10mm socket wrench to fix the
two horns to the support using four
M6 bolts, four M6 nuts, four M6
gaskets, and one tripod. Install the
bolts through the tripod - through
the horn, through the gasket, and
lock the nuts.
