POWER SUPPLY INSTALLATION DRAWING
Electrical diagram of the beautiful line (black, white, green E)
This figure is only for three-phase power in the United States, and the voltage
between two live lines is 240VAC
Three core cable machine connection drawing
2 4 0 V 4 0 A
L 1
L 2
E
L2L 1
The leakage switch
Leakage switch of power supply box
L 1
L 2
2 2 0 - 2 4 0 VA C
Electric ceramic oven power cord
black
white
green
black
white
green
2 2 0 V 4 0 A
L
N
E
NL
The leakage switch
Leakage switch of power supply box
L
N
2 2 0 V A C
Electric ceramic oven power cord
black
white
green
black
white
green
Electrical diagram of the beautiful line (black, white, green E)
This chart is only applicable to 220 V single-phase power countries in
Europe and China
Three core cable machine connection drawing
Earth wire Earth wire
Earth wire Earth wire
