INSTALLATION
After unpacking the product, check for any damage during transport. In
case of problems, contact the dealer or the After-Sales Service.
For built-in dimensions and installation instruction, see in below figures
The distance between the underside of the appliance and the
separator panel must respect the dimensions given in the
figure (mini. 50mm).
In order to ensure the correct operation of the product, do not obstruct
the
minimum required
clearance (min. 20 mm) on the worktop for
air flow out.
If an undertop oven is installed, make sure the oven is equipped with a
cooling system.
Do not install the hob above a dishwasher or washing-machine, so that
the electronic circuits do not come into contact with steam or moisture
which could damage them.
