VEVOR T45K - Component Diagram

- 4 -
DC24V
DC24.6V OFF
DC26.0V ON
DC22.3V OFF
DC23.7V ON
DC21.3V OFF
DC22.7V ON
Note: When the power supply is connected and the refrigerator is turned on,
disconnecting or starting refers to disconnecting or starting the compressor.
Component Diagram
1. Cabinet 2. Classified plate
3. Case Cover 4. Door buckle
5. Sealing Strip 6. Control panel
7. Handle ( optional ) 8. Wheel ( optional )
9. Power Interface
