20
21
FLX-30™BB FLX-28™ FLX-20™ FL-18™ FLX-12™ FL-8™SE
Display Type Weatherproof, super-bright, 5-color LED (five color
palettes).
Weatherproof, super-bright,
3-color LED (3 color palettes).
Weatherproof, super-bright, 3-color LED (strong targets in red, medium
targets in orange, weak targets in green).
Display Face Flat screen with super wide viewing — more than one angler can see the display — and from
farther away or from the sides.
Backlit scale decal
with light trap
design.
Flat screen with backlit
scale and super wide
viewing angle.
Backlit scale decal with
light trap design.
Flasher Technology Effective in 2020, All Vexilar Flashers are being produced using Vexilar’s proprietary brushless data transfer technology to deliver a sunlight-readable display and less noise.
Resolution 525 segments. Target
separation of ½ inch (at 10’
range setting).
525 segments. Target
separation of ½ inch (at
10’ range setting).
525 segments. Target
separation of ½ inch (at 10’
range setting).
525 segments.
Target separation
of 2.6 inches.
525 segments. Target
separation of 1.0 inch.
525 segments. Target
separation of 2.6 inches.
Target ID Less than ¼ inch Less than ¼ inch Less than ¼ inch Less than ½ inch 1 inch 1 inch
Auto Zoom settings 6’, 12’ and 18’ Auto Zoom. 6’ and 12’ Auto Zoom. 6’ and 12’ Auto Zoom. 6’ Auto Zoom.
6’ Bottom Lock.
n/a n/a
Low power Mode Three power mode settings:
Low, Medium and High
Built-in Built-in Built-in Built-in With optional S-Cable
Night Mode Built-in Built-in Built-in n/a Built-in n/a
Interference rejection 20 settings per frequency (140
options)
20 settings 20 settings 10 settings 20 settings 10 settings
Depth range settings
(feet)
Auto: 10, 15, 20, 25, 30, 40,
50, 60, 80, 100, 120, 160, 200,
240, 300
Shallow: 10, 15, 20, 30, 40
Medium: 50, 75, 100, 125, 150
Deep: 175, 200, 225, 250, 300
Auto: 10, 15, 20, 25,
30, 40, 50, 60, 80, 100,
120, 160, 200, 240, 300
Manual: 10, 20, 30,
40, 50
10, 20, 30, 40, 80, 100
Deep Water: 30, 60, 90, 120,
240, 300
20, 40, 60, 80, 200 20 (Low Power), 20, 40,
60, 80, 120
20, 30, 40, 60, 80, 120
Sonar longevity MST matching sonar technology ensures maximum sonar performance and longevity by balancing the transmitter and receiver to the transducer crystal.
Battery status Battery status & low battery alert Low battery alert n/a Low battery alert n/a
Digital depth display Built-in With optional Digital Depth Indicator (DD-100)
Operating voltage 10.5–15 volts (12 volts nominal)
Current draw 300 mA @ 12 volts 260 mA @ 12 volts 220 mA @ 12 volts 200 mA @ 12 volts 240 mA @ 12 volts 250 mA @ 12 volts
Power output 1000 watts (peak to peak) 400 watts (peak to
peak)
1000 watts (peak to peak) 400 watts (peak to peak)
Frequency Variable 160–300 kHz 200 kHz
Ice-Ducer™ options Broad band Ice-Ducer™
transducer
Pro-View only 12°, 19° and Pro-View compatible.
Dimensions 4.8”H x 6”W x 2.4”D 4.8”H x 6”W x 2.4”D 4.8”H x 6”W x 2.4”D 4.4”H x 6”W x
3.5”D
4.8”H x 6”W x 2.4”D 4.4”H x 6”W x 3.5”D
Weight 1.1 lb 1.1 lb 1.1 lb 1.1 lb 1.1 lb 1.1 lb
FEATURES & SPECIFICATIONS
A TRADITION OF EXCELLENCE AND KNOWLEDGE TO SHARE WITH
FRIENDS AND FAMILY!
For over a half a century, anglers have started many great shing adventures by turning on a Vexilar. Now with over a half million Vexilar units in
use today, it’s no wonder serious anglers proudly state:
“They will never go shing without their Vexilar!”
This Owner’s Manual is to serve as a foundation of knowledge to get you started using your Vexilar. Reading the sections of this manual that
applies to your system will avoid confusion and actually go a long way in helping you extend the life of your Vexilar product as well.
They often say: “Knowledge is power” and with the knowledge from this manual we hope you will share with other Vexilar owners who were not
as pro-active enough to read about how to get the most out of their Vexilar. From the tricks on how to adjust your gain level to how to properly
use the Interference Rejection system all to make for a more enjoyable day on the water.
It might seem simple, but it is the little things that many anglers overlook when they are in a rush to get out on the water. We thank you for taking
the time to study and learn about your Vexilar system, and we hope you can also share your new-found knowledge with your friends.
