Vexta FBL II Series User Manual

1
2
3
3
2
1
4
5
6
7
8
9
10
11
12
INPUT COM
EXT.VR.
CW
CCW
SLOW DOWN
SW1 Speed selection
SW2 Clockwise rotation input
SW3 Counterclockwise rotation input
SW4 Deceleration input
Speed output
GND
Alarm output
GND
N.C.
H
M
L
GND
SPEED OUT
ALARM OUT
EXT.
Set at time of shipment.
When controlling from a programmable
controller or other external power supply.
INT.
When controlling with a relay or switch.
Three-phase200V−230V±10％
Power capacity varies with output
power of the motor.
Motorcable（0.5m）
Motor
Twisted Pair Line
Shielded wire Speed potentiometer
(accessory)
Protectiveearth

Earth
Driver
External DC power supply+24V
A connection to this terminal is not necessary
when using the driver's built-in power supply.
OFF
ON
OFF
ON
OFF
ON
OFF
ON
1
3
2
S.S.
S.D.
SPEED
FG
L2
L3
L1
BRUSHLESS DC MOTOR
DRIVER FBLD120SW
VEXTA
1
2
3
4
5
6
7
8
9
10
11
12
I/O
POWER
ALARM
EXT.–INT.
MOTOR
11
■Input power of three phase types
4．3 MotorandDriverConnections
Themotorisconnectedtothedriverusingtheconnectorsprovided.Thecablecanbeextendedtoamaximumof
10.5metersusinganextensioncable(soldseparately).
Note Do not lengthen the motor cable by more than 10.5 meters by connecting two or more extension cables, as this
can lead to faulty operation.
Model
CC01FBL
CC02FBL
CC03FBL
CC05FBL
CC07FBL
CC10FBL
Cable Length
3.3ft. (1m)
6.6ft. (2m)
9.8ft. (3m)
16.4ft. (5m)
23.0ft. (7m)
32.8ft. (10m)
