AMPLIFIER PANEL
1. USB Player
2. Volume 1 : Control the Volume of Microphone input .
3. Volume 2: Control the Volume of line in
4. Volume: Control the Volume of MP3
5. Volume: Control the Volume of MP3, microphone, Line in,
Aux, Bluetooth.
6. 3.5mm input connector
7. Equalizer: to control the high tone level -12dB to + 12dB
8. Equalizer : to control the low tone level -12dB to + 12dB
9. 1/4 Jack for Mic input
10.
RCA Connector to device like CD, Tuner or mixer, etc ,RCA
balanced
11.XLR Connector for Mic Input
12.Line Input
13.Signal Output
14.Power Switch: It allows to switch on/off the unit
15.Main supply inlet : 230Vac / 50Hz
MODE
Exchange between USB / SD / Bluetooth
Play/Pause
Repeat
Last
Next
Bluetooth
