STEP
1
STEP 2
STEP 4
STEP 3
6
*1
*2
*1
74
95
89
87
88
80
72
71
13
www.viavito.com
Step Six.
01 Unscrew the stoppers (87), the axle
(88) and the screw (89) on both sides of
the aluminium rail.
02 Slide the seat (95) onto the rail (71)
and ensure the seat is facing the front
of the rower with the ridged end at the
rear.
03
the stoppers (87), the axle (88) and
the screw (89) back on to the rail.
04 Unscrew the screw (74) from the rear
foot (72) then place the end cover (80)
on the rear foot (72). Fix in place using
the screw (74).
