Viconics VZ7260 5 00B Series User Manual

4
• Proper wiring of all components as per the installation manual
• Proper network wires pulled through all devices communication connections
Zone Controllers Available Models & Features:
V
iconics Part
Number
VZ7260F5000B VZ7260F5500B VZ7260C5000B VZ7260C5500B
Control
Outputs
2 x Analog 0 to 10 VDC
1 x Auxiliary reheat
contact
2 x Analog 0 to 10 VDC
1 x Auxiliary reheat
contact
2 x Tri-state floating
1 x Auxiliary reheat
contact
2 x Tri-state floating
1 x Auxiliary reheat contact
PIR Cove
r
PIR cover ready. PIR cover factory installed PIR cover ready PIR cover factory installed
Master Controllers Available Models & Features:
V
iconics Part
Number
VZ7656R1000B VZ7656H1000B VZ7656F1000B VZ7656E1000B
Controlled
Equipment
Rooftop Unit Heat Pump Unit Rooftop Unit Rooftop Unit
Main Control
Outputs
2H / 2C 3H / 2C 0-10VDC Analog Heat / 2C 2H / 2C
Unique
Features
-
- Reversing Valve
Output
- 0-10VDC Analog Heat
Output
- Minimum Supply Air
Temperature Control
- 0-10VDC Fresh Air Damper Output
- 0-5VDC Airflow Sensor Input
- CO2 Level Control Sequence
- Free Cooling Economizer Sequence

Viconics VZ7260 5 00B Series Specifications

General

Brand	Viconics
Model	VZ7260 5 00B Series
Category	Controller
Language	English
