Machine Layout & Supplied Items straight shaft TTS2226
1 Cast trimmer head
2 3mmØ Nylon line
3 Straight shaft guard
4 Lower straight shaft
5 Handle
6 Engine stop switch
7 Throttle lever "release"
8 Throttle lever
9 Throttle lever "lock"
10 Choke lever
11 Starter cord
12 Spark plug boot
13 Air filter housing cover
14 Fuel Tank (Use 2-Stroke Fuel & Oil Mix, see pg.19)
15 Cowling
16 Fuel pump "primer"
17 Shoulder strap
18 Shaft split connection
19 Spark plug wrench
20 Allen key (4mm)
21 Allen key (5mm)
22 Spanner
Do not operate the VICTA Trimmer
before reading all Safety &
Handling sections.
To Next Page
