OPERATION
Test 1 — Engine should NOT crank if:
• PTO switch is ON, OR
• Brake pedal is NOT fully depressed (parking brake
OFF), OR
• The cruise control lever is NOT in NEUTRAL.
Test 2 — Engine SHOULD crank if:
• PTO switch is OFF, AND
• Brake pedal is fully depressed (parking brake ON),
AND
• The cruise control lever is in NEUTRAL.
Test 3 — Engine should SHUT OFF if:
• Operator rises o seat with PTO engaged, OR
• Operator rises o seat with brake pedal NOT fully de-
pressed (parking brake OFF).
Test 4 — Check Mower Blade Stopping Time
Mower blades and mower drive belt should come to a
complete stop within ve seconds after electric PTO
switch is turned OFF. If mower drive belt does not stop
within ve seconds, see an authorized dealer.
Test 5 — Reverse Mow Option (RMO) Check
• Engine should shut o if reverse travel is attempted
if the PTO has been switched on and RMO has not
been activated.
• RMO light should illuminate when RMO has been ac-
tivated.
NOTE: Once the engine has stopped, the PTO switch
must be turned o after the operator returns to the seat in
order to start the engine.
12
Oil Recommendations
We recommend the use of Briggs & Stratton Warranty
Certied oils for best performance. Other high-quality
detergent oils are acceptable if classied for service SF, SG,
SH, SJ or higher. Do not use special additives.
Outdoor temperatures determine the proper oil viscosity for
the engine. Use the chart to select the best viscosity for the
outdoor temperature range expected.
** Above 80° F (27° C) the use of 10W30 may cause
increased oil consumption. Check oil level more
frequently.
* Below 40° F (4° C) the use of SAE 30 will result
in hard starting.
80
60
40
120
100
°F
-20
°C
20
Synthetic 5W30
5W30
0
27
15
4
49
38
-29
-7
-18
SAE 30 *
10W30 **
Oil Recommendations
Safety Interlock System Tests
This unit is equipped with a Safety Interlock System. Do not
attempt to bypass or tamper with the switches and devices.
WARNING
If the unit does not pass a safety test, do not operate
it. See an authorized dealer.
WARNING
Mowing in reverse can be hazardous to bystanders.
Tragic accidents can occur if the operator is not alert to the
presence of children. Never activate the RMO if children
are present. Children are often attracted to the unit and the
mowing activity.
Oil Pressure
If the oil pressure is too low, a pressure switch (if equipped)
will either stop the engine or activate a warning device on
the equipment. If this occurs, stop the engine and check the
oil level with the dipstick.
If the oil level is below the ADD mark, add oil until it reaches
the FULL mark. Start the engine and check for proper
pressure before continuing to operate.
If the oil level is between the ADD and FULL marks, do not
start the engine. Contact an authorized dealer to have the
oil pressure problem corrected.
