Hanging Board
Decorative Board
Ceiling Mount
Unit: JUPITER
Aluminum
Mesh Filter
CONTROL PANEL
ON RANGE HOOD
Timer
Lights
Fan Blower
On / Off
If y our ceiling height is
more than 8 feet, a longer
main power cable will be
required to be i nstalled
by a certified electrician
*
13 ¾”- Ø
15”
1”
Combined length of
stainless steel cable
and hood unit can
reach up to 65”
(will fit 8’-10’ ceiling)
VICTORY range hoods
| JUPITER
8
VICTORY range hoods
JUPITER |
9
PARTS SUPPLIED (Continued)
