Victory Jupiter - Installation

JoistJoistJoist
120v Power120v Power120v Power
Ceiling
Will fit 8ft-10ft
(If your ceiling height i s
more than 8 feet, a longer
main power cable will be
required to be installed by
a certified electrician)
36”
(Typical)
24” minumum
30” maximum
JUPITER Hood Unit
centered above stove
Combined length of
stainless steel cable
and hood unit can
reach up to 65”
VICTORY range hoods
| JUPITER
10
VICTORY range hoods
JUPITER |
11
INSTALLATION
