Victory LUNA - Dimensions

19 ¾”
6”
1 ¾”
29 ½”
Ø 6” Transition
BOTTOM VIEW
BACK VIEW
SIDE VIEWFRONT VIEW
TOP VIEW
Includes Rectangular Exhaust
Connector (with plate adaptor)
Hood shown: LUNA 30
Please refer to next pages for
available models and their
respective dimensions
| LUNA8 LUNA | 9
DIMENSIONS
