32”
13”
Cut-Out
Island St
ove
Counte
rtop
Ceiling
Wall
Joist
Orientation of Joists
must match island stove
Orientation of Joists
must match island stove
Cut-out ceiling board
must be installed
in between joists
Align centre placement
of range hood with
centre of island stove.
Align centre placement
of range hood with
centre of island stove
Installation Holes
the joists.
Please NOTE: The orientation of the joists
and the orientation of the stove must
match.
If the orientation does not match, the range
hood may need to be dropped down into a
box in order to rotate it.
(A) .
installment.
holes on both side walls to fasten screws on
| SUNSET12
ROUGH
-
IN
(A)
Swing
Open
Door
(B) Remove Filters
To Next Page
