Ceiling
Height
Venting Requirements
Page5
Height & Clearance
IslandRange
hood
36”
Min:
28”
Max:36”
• Vent system must terminate to the outside
(rooforsidewall).
• DONOTterminatetheventsysteminanat-
tic or other enclosed area.
• DO NOT use smaller than 8” wall caps.
• Usemetal/aluminumventonly.Rigidmetal/
aluminum vent is recommended.
• DO NOT use plastic vent.
• Alwayskeeptheductcleantoensureproper
airow.
• Calculatethefollowingguresbeforeinstal-
lation:
1. Distance from the oor to the ceiling.
2. Distance between the oor to the coun-
tertop/stove (recommend* 28” to 36”).
3. Distance between the countertop/stove
to the range hood.
4. Height of hood and duct cover.
For the most efcient & quiet operation:
• A distance of 28” to 36” is recommended*
between stove top and the bottom of range
hood.
• It is recommended that the range hood be
ventedverticallythroughtheroofthrough8”
orbiggerroundmetal/aluminumventwork.
• The size of the vent should be uniform.
• Usenomorethanthree90°elbows.
• Make sure there is a minimum of 24” (61
cm) of straight vent between the elbows if
more than one elbow is used.
• DO NOT install two elbows together.
• The length of vent system and number of
elbowsshouldbekepttoaminimumtopro-
videefcientperformance.
• Theventsystemmusthaveadamper.Make
sureyourooforwallcapcomeswithone.If
it doesn’t, install inline damper.
• UsealuminumtapeONLYtosealalljoints
intheventsystem.
• Use caulking to seal exterior wall or roof
openingaroundthecap.USE8”ROOFOR
WALLVENTCAPMINIMUM.
*Duetodifferentceilingheightcongurations,rec-
ommendedheightmaynotbeapplicable.
19.5”
Adjustable
chimney
covers
Countertop/Stove
Numberofltersvary,dependingonthesizeofyourrangehood,sameforthenumberoflight
