OVERVIEW
Back View
AC Power
Port
AUX-In
Port
RCA
Ports
Power
Switch
SUB-OUT
Port
SP-L
Port
SP-L
Port
Function
Knob
CONNECT THE TWO MONITORS
WITH THE BLACK SPEAKER CABLE
