6-6 Clean the Printhead Rev AA
Videojet 1710 Operator Manual
Clean the Printhead
PERSONAL INJURY. In the event of an ink or solvent spill, leakage
from the printer could cause a floor/slip hazard and/or fire hazard
(particularly if the equipment is situated over flammable material
and/or other equipment). An optional drip tray is available (Part
Number 234407). To install, place the drip tray on surface that the
printer is to be used. Place the printer in the centre of the drip tray.
Ensure that the drip tray is appropriately grounded to avoid static
build up.
1
2
3
4
5
6
7
8
9
1. Umbilical
2. Printhead Screw
3. Printhead Cover
4. Nozzle
5. Deflector Plate
6. Gutter Sensing Tube
7. Charge Electrode
8. Printhead Engine
9. Printhead Valve Module
Figure 6-4: Printhead
