Rev AA Ink and Make-up Fluid Capacity A-7
Videojet 1710 Operator Manual
department at 800.843.3610 (United States only), or contact the local Videojet
Technologies Inc. for more information.
Ink and Make-up Fluid Capacity
The ink and solvent capacity of the printer are shown in Table A-6.
Print Height
The minimum and maximum height of the message for the print matrix is
shown in
Table A-7.
Nozzle Frequency
Font Specifications and Line Speeds
The font specifications and the line speeds for 60 and 70 micron nozzle are
shown in
Table A-9 on page A-8Table A-10 on page A-9.
Ink Cartridge 600 milliliters
Make-up Fluid
Cartridge
750 milliliters
Table A-6: Ink and Make-up Fluid Capacity
Print Height 60 Micron Nozzle 70 Micron Nozzle
Minimum 2.5 mm 2.0 mm
Maximum 13.0 mm 10.5 mm
Table A-7: Print Height
Nozzle Frequency 60-68 KHz (variable),
64KHz (nominally)
Table A-8: Nozzle Frequency
