A-8 Font Specifications and Line Speeds Rev AA
Videojet 1710 Operator Manual
Note: The optimum value is 12 mm. The range is 5 to 15 mm.
Note: The line speeds listed in the Table A-9 and Table A-10 on page A-9 are for
60 dpi only.
a
- These are non-linear rasters
Line
Mode
Font
Height
Font
Width
Speeds
fpm m/min
1 5 5 888 271
1 7 4 800
244
b
1 7 5 666 203
1 9 7 444 135
1 12 9 266 81
1 16 10 253
77
a
1 24 16 79 24
1 34 25 46 14
2 5 5 313
95
a
2 7 4 400
122
ab
2 7 5 333 101
2 9 7 190 58
2 12 9 71 22
2 16 10 46 14
3 5 5 104 32
3 7 4 220
67
ab
3 7 5 183
56
a
3 9 7 100
30
a
4 5 5 71 22
4 7 4 55
17
b
4 7 5 46 14
5 5 5 46 14
Table A-9: Line Speeds - 60 Microns
