VIDEOJET 1710 - Chapter 3 - Main Parts

Rev AA Videojet 1710 Printer 3-1
3
Main Parts
Videojet 1710 Printer
1
2
4
5
3
1. Control Panel
2. Ink Compartment
3. Umbilical
4. Printhead
5. Connector Panel
6. Electronics Compartment*
7. On/Standby Switch*
8. Back Filter*
Figure 3-1: Main Parts of the Printer
*The components are not shown in the picture.
