1. [DUR] displays and allows changes to be made to the duration of the
current event.
1. From the EDL, [SETUP] displays the first of two Setup Menus. Pressing
[SETUP] while either of the two menus is displayed takes you back to the
last-displayed EDL event.
2. [SHIFT]+[DELETE]+[SETUP] from the EDL resets the Configuration
parameters to factory default settings.
3. [GO TO]+[0/Setup] rewinds VCRs and camcorders whose PROTO is LANC
or PANA, and resets their counters to 0000.
1. [CHG] cycles through choices in a choice list or activates the numeric keys
when in a numeric field.
2. [SHIFT]+[CHG] when connected to an MX-1, cycles the MX-1 display
between the Next Source, the Current Source and the Preview Screen.
3. [SHIFT]+[GO TO]+[CHG] resequences all EDL event numbers.
1. [OK] accepts changes made to a field value.
2. [SHIFT]+[OK] redisplays the last error message.
3. [GO TO]+[OK] accesses the Go To Event# function. (Finds the event whose
number is entered. )
