Videx 136 User Manual

66250600-EN - V3.0 - 15/09/16
2
4000 Series Vandal Resistant Line
Art.136 - Installation instructions
4 WAY DIP-SWITCH
Switch Status Operation
1
OFF 2 minutes
ON 1 minute
2, 3
OFF OFF 2 seconds
OFF ON 4 seconds
ON OFF 8 seconds
ON ON 20 seconds
4
OFF System recall disabled
ON *System recall by handset pick-up
* The system recall by handset pick up can be enabled only
on one entrance audio door entry systems.
JUMPER (REASSURANCE TONE)
Position Operation
High Reassurance tone enabled with high volume
Low Reassurance tone enabled with low volume
No jumper Reassurance tone disabled
Note: If the reassurance tone is enabled, the door opening is
also conrmed by a tone.
FRONT LEDS – SIGNALLING DESCRIPTION
LED Description
Yellow Illuminates during the conversation
Red Illuminates to advise that the call is not allowed
beacuse another door panel is in conversation in
the system
Green Illuminates when the door opens for the dura-
tion of the door opening time
CONNECTION TERMINALS
Terminal Signal description
1 Speech line input toward the speaker
2 Speech line output from the microphone
+ +12Vdc input
– 0V (Ground)
5 Switched 0V from phone to trigger door release relay
T Electronic call tone output to common side of call button
– 0V for use with push to exit input (PTE)
PTE Switched 0V input from push to exit button to trigger door release relay
C Common connection of dry contact relay
3 Amp AC/DC
24V max
NC Normally closed connection of dry contact rela
NO Normally open connection of dry contact relay
D+ External link to door open (+12V side) LED.
D– External link to door open (0V side) LED.
BSY Busy signal for use with multiple door systems (Normally high, 12V. Low when busy 0V)
SL Switched 0V output. (0V throughout a call, open collector in standby)
F1 Switched 0V output to switch on camera or. (0V throughout a call, open collector in standby)
TECHNICAL SPECIFICATION
Power Supply: 12Vdc
Power consumption: Stand-by: 25mA
During a call: 150mA
During a conversation: 70mA
Working Temperature: -10 +50 °C
Art.136 Speaker unit for audio door entry systems "4+1" and video door entry systems
