The restriction valve is not clogged and that water flows freely
trough the outlet.
CLOGGED
OUTLET
(NO RESTRICTION)
The water pump supply voltage is correct: 9.8 V minimum.
Important: Measure at the pump's connector with the pump
working and the turbo blower at maximum speed.
The water pump consumption (Amp) is between the specified
values: between 3.7A and 6.0A (with water running through).
Important: Remove the fuse and measure at the fuse box while
the pump is running and the biturbo blower is off.
The water pump electrical connections are correct.
RED (+)
BLACK (-)
BLACK (-)
RED (+)
RED (+)
BLACK (-)
BLACK (-)
RED (+)
YES
NO
