GB
General notice (liability): the details of this technical documents serve for description. Consents regarding the availability of certain features or
regarding a certain purpose always require a special written agreement.
Page No. 10-GB 4.1 We reserve the right to make technic changes!
4.1 Connecting a remote control unit (SD Control)
In case the unit has been ordered with a remote control,
attach the remote control at the designated location and
plug in the adapter via the 10-pole flat ribbon cable to the
back side of the control unit. Attach the adapter with the
enclosed cable binders to the rear wall of the control hou-
sing. (with bus control, see Bus control manual)
