Symbol Meaning
Reference to other document containing
further information
Step in a diagram:
The numbers correspond to the order in
which the steps are carried out.
Warning of material losses and environ-
mental pollution
Live electrical area
Pay particular attention.
■
Component must audibly click into place.
or
■
Acoustic signal
■
Fit new component.
or
■
In conjunction with a tool: Clean the sur-
face.
Dispose of component correctly.
Dispose of component at a suitable collec-
tion point. Do not dispose of component in
domestic waste.
Product information
The energy meter determines by means of 3 current
sensors (standard delivery) whether there is an excess
of on-site generated power. This information is passed
on via the connection to the output control module. In a
continuously variable feed, the output control module
then feeds the excess power generated on site to an
immersion heater in the DHW cylinder, e.g. the Vitocell
100-B, type CVE.
Information
Symbols
5678 581 GB
